PLAST-O-MATIC CAFE NITRO FAST

Photo PLAST-O-MATIC CAFE NITRO FAST  Descriptions PLAST-O-MATIC CAFE NITRO FAST Specifications PLAST-O-MATIC CAFE NITRO FAST User Manual for PLAST-O-MATIC CAFE NITRO FAST  Related instruments to PLAST-O-MATIC CAFE NITRO FAST

PLAST-O-MATIC CAFE NITRO FAST Electric Actuators

PLAST-O-MATIC CAFE NITRO FAST Electric Actuators
PLAST-O-MATIC CAFE NITRO FAST Electric Actuators

With engineering, manufacturing, assembly and programming all provided by Plast-O-Matic, CAFE actuators are available with a wide range of voltage and performance options, as well as mounting and connections for virtually any valve requiring torque up to 20 Nm.
Minimum quantities may apply, depending on level of customization.



Warning:  Undefined variable $term_list in /home/users/o/olil/domains/dolcetrade.com/wp-content/themes/olil2/template-parts/post/content-listing-with-gallery.php on line 76

int(17428)
NULL

Made in USA. brand PLAST-O-MATIC, model CAFE NITRO FAST

International delivery to Europe, Asia and Africa.
Our warehouses are located in the UK, UAE and Senegal.

price by request

Available

Available

Advantages

Only the best I&C brands

Our company is a global supplier of control and measuring instruments from well-known world brands

Advantages

Discounts for organisations

We sell high-tech equipment at very low prices. We provide really advantageous conditions for partners

Advantages

Fast delivery across the Europe & Asia

We take care of all logistics and customs clearance of I&C solutions from Europe, USA, China and India

Advantages

Professional advice on device selection

Our specialists are ready to advise you on any technical question. We can find an analogue of any device

Descriptions of PLAST-O-MATIC CAFE NITRO FAST

STANDARD CAFE FEATURES

  • Multi-Voltage 24-240V AC/DC, 50-60 Hz Input Power with auto-voltage sensing
  • LED status light to indicate operational status of actuator
  • Multi-Mode Electronic over-torque protection against valve jam Brushless motor with ICP protection
  • Thermostatic anti-condensation heater
  • Remote position indicator via Programmable relays
  • Barrel style visual position indicator
  • Weatherproof anti-corrosive and UV protected glass filled polypropylene housing
  • Easy mounting with ISO 5211
  • All external electrical connections via DIN plugs
  • Soft Reset via DIN plugs
  • CE, UKCA, SGS/C/US, FCC marked
  • IP67 ingress protection
  • Plast-O-Matic engineered & assembled in USA
  • Range of 90° working time 5 seconds
  • Fail-safe option w/battery backup

CAFE NITRO FEATURES

  •  Includes all features of CAFE, plus…
  • OLED screen
  • Over-torque & over-temperature alarms
  • (0-20, 4-20) mA or (0-10, 2-10) V DC proportional closed loop control options
  • Differential input/output proportional closed loop control options
  • Proportional Control Loop with over voltage and overcurrent protection
  • Modbus RS485 proportional control option with 13 registers
  • Fail-safe option w/battery backup
  • Stand alone control option via asynchronous calendar
  • Three different drive mode options: Auto, keypad, manual
  • Alarm log option • Run time diagnostic option
  • Range of 90° working time programmable from 5 – 10 seconds

CAFE NITRO FAST FEATURES

  • Range of 90° working time programmable from 1 – 5 seconds
  • Includes all features/options of CAFE NITRO



Technical specifications of PLAST-O-MATIC CAFE NITRO FAST

Sizes 3/8″-2″ Ball Valves
Actuator CAFE CAFE NITRO CAFE FAST
Input Voltage (+1.1 VR   / -0.85 VR ) 24 Vdc, 24 Vac, 110-240 Vac 24 Vdc, 24 Vac, 110-240 Vac 24 Vdc, 24 Vac, 110-240 Vac
Frequency DC, 50Hz/60Hz DC, 50Hz/60Hz DC, 50Hz/60Hz
Working Time 0-90° No Load) ±10% 5 seconds preset  5 seconds preset – up to 10 sec via display 1 second preset – up to 5 sec via display
Multivoltage Maximum Run Torque (Nm/ in-lbs.)* 15 / 133 15 / 133 10 / 88.5
Maximum Break Torque (Nm/in-lbs.) 20 / 177 20 / 177 20 / 177
On/Off Duty Rating % 75 75 75
Modulating Duty Rating % 100 100 100
IP Rating—IEC 60529 IP67 IP67 IP67
Working Angle Standard 90°/180° 90°/180° 90°/180°
Application Indoor ** Indoor** Indoor**
Temperature Range (°F / ºC) -4 to 122 / -20 to 50 -4 to 122 / -20 to 50 -4 to 122 / -20 to 50
Anti-Condensation Heater (W) 3.5 3.5 3.5
Input Power (@24VDC)max 35 W 35 W 35 W
Current Full Load: 24Vdc, 24Vac 1p 50/60Hz, 110–240Vac 1ph 50/60Hz 1.4 A, 1.5 A, 0.3 – 0.15 A 1.4 A, 1.5 A, 0.3 – 0.15 A 1.4 A, 1.5 A, 0.3 – 0.15 A
Discrete Control Input Input Power Input Power Input Power
Analog Control Input 0-10V,2-10V,0-20mA,4-20mA 0-10V,2-10V,0-20mA,4-20mA
Discrete Output (Volt Free) Relay (ON/OFF) Relay (Programmable) Relay (Programmable)
Discrete Output Activation offset approx. 5° approx. 5° approx. 5°
Analog Control Output – 0-10V,2-10V,0-20mA,4-20mA 0-10V,2-10V,0-20mA,4-20mA
Analog Control Impedance – 6.1 KOhm 6.1 KOhm
Analog Load Impedance – 50 KOhm (V) – 600 Ohm (A) 50 KOhm (V) – 600 Ohm (A)
Max Current per Discrete Output (Resistive) 4 A 4 A 4 A
Max Voltage per Discrete Output 240 VAC/DC 240 VAC/DC 240 VAC/DC
Resistance per Discrete Output 25 mOhm 25 mOhm 25 mOhm
Communication Control IN/OUT – MODBUS RS 485 MODBUS RS 485
Comm. Baud Rate – 9600, 19200, 57600 Baud 9600, 19200, 57600 Baud
Comm Available Registers – 12 12
Local Signaling Multicolor LED Multicolor LED Multicolor LED
Manual Remote Signaling – Supported** Supported**
Event Scheduler – Supported** Supported**
User Interface – OLED w/full navigation Keypad OLED w/full navigation Keypad
Electrical Interconnections Field Attachable Type A,C Field Attachable Type A,C Customization

Supported

 Field Attachable Type A,C Customization Supported
Fail Safe – Supported*** Supported***
Enclosure GF-PP GF-PP GF-PP
Weight (kg/lbs) 1.25kg / 2.75 lbs. 1.25kg / 2.75 lbs. 1.25kg / 2.75 lbs.
Drive Socket 14 mm Double Square 14 mm Double Square 14 mm Double Square

User Guide and Instruction manual for PLAST-O-MATIC CAFE NITRO FAST

You can request the necessary certificates, documentation, instructions and user manuals for PLAST-O-MATIC CAFE NITRO FAST  using the special form.

You can buy PLAST-O-MATIC CAFE NITRO FAST  in UK or Europe at a favourable price in «DOLCHETRADE» by leaving a request on the website, by phone +441225535040 or by email . PLAST-O-MATIC CAFE NITRO FAST  price are subject to change depending on exchange rates. We deliver instruments by transport companies in the United Kingdom and Europe.

See also: Ball Valves,  Valves & Fitting
